Input Voltage Range (V)

90-130V or 170-265V (110/220V )

Input current range (A)

0.1-3A

Operating frequency (Hz)

50Hz?60Hz

Efficiency

83% (230VAC at full load)

Surge Current (A)

cold start <40A/230VAC

Leakage current (mA)

<3.5mA/240VAC

Output Voltage (V)

24VDC

Tolerance

+3,-2%

Rated output current (A)

10A

Output current range (A)

0 ~ 10A

Nominal Rated Power (W)

240W

Start, hold time (ms)

Ton = 1000ms, Td = 20ms @ 230Vac full load

Rise time (ms)

Typ: 20ms @ 230Vac full load

Ripple / Noise (MVP-P)

<120mVp-p

temperature

0?C - +40?C

Storage Temperature (?)

-20?C - +60?C

Humidity (%)

20% - 90% RH non-condensing

pressure (VAC)

I/P-O/P:1.5KVAC,I/P1min

SAFETY STANDARDS

Under EN/UL60950-1, GB4943 standard design

EMC standards

EN55022 Class B, EN61000-4-2, 3,4,5,6,8,11 GB17626.5

Level3 standard design

Over voltage protection

115% -135%

Overload protection

105%-150%

Short Circuit Protection

Protection type: Shut down o, automatic recovery
